GENERAL PERFORMANCE
Rated Lifting Capacity: 120 tonnes
Maximum Load Moment: 3,567 kN·m
Drive / Steering: 4×4 Rough Terrain
Maximum Travel Speed: 30 km/h
ENGINE & CHASSIS
Engine: Cummins L9
Engine Power: 231 kW
Axles: 2
Travel Weight: Approx. 70,000 kg
Dimensions (L×W×H): 15,580 × 3,490 × 3,980 mm
BOOM & JIB SPECIFICATIONS
Main Telescopic Boom Configuration: 1 base + 4 telescopic sections
Base (Retracted) Boom Length: 12.9 m
Fully Extended Boom Length: 50.0 m
Optional Lattice Jib Length: 10.8 m 18.3 m
Jib Offset Angles: 0°, 15°, 30°
Maximum Tip Height (Boom + Jib): Approx. 68.3 m

XCMG XCR120_AU

XCMG XCA4000 Ultra-Heavy All-Terrain Crane
The XCMG XCA4000 is the worlds most powerful wheeled all-terrain crane, setting a new global benchmark in ultra-heavy lifting. With a maximum rated lifting capacity of 4,000 tonnes, the XCA4000 is purpose-built for large-scale infrastructure, petrochemical, and next-generation wind energy projects where extreme height, reach, and load capacity are required.
Technical Specifications
General
Item Specification
Model XCA4000
Crane Type All-Terrain Wheeled Crane
Maximum Rated Capacity 4,000 tonnes
Primary Applications Ultra-heavy lift, wind energy, infrastructure
Boom & Lifting Performance
Item Specification
Main Boom Type Telescopic, high-strength steel
Main Boom Length Approx. 85 m
Boom Sections Multi-section modular design
Maximum Lifting Height Over 170 m (with configuration)
Max Load at Height Approx. 230 t at 170 m
Chassis & Mobility
Item Specification
Axles 11-axle all-terrain chassis
Steering All-wheel steering
Suspension Heavy-duty hydraulic suspension
Power & Control
Item Specification
Engine High-performance diesel engine(s)
Hydraulic System High-capacity intelligent hydraulic system
Safety Integrated active safety & monitoring systems

XCMG XCA4000

XCMG
Model: XGC400-1
Lattice Boom Crawler Crane
Maximum Rated Capacity: 400 tonne
Standard Heavy Boom Range: 24m 84m
Standard Light Boom Range: 42m 108m
Superlift Heavy Boom Range: 36m 96m
Superlift Light Boom Maximum: Up to 126m (with superlift configuration)
Minimum Boom Length: 24 metres
Maximum Boom Length (Light + Superlift): 126 metres
Boom Configuration Summary Table
Configuration Boom Range Notes
Heavy Boom 24m 84m High capacity configuration
Light Boom 42m 108m Extended reach, reduced weight
Superlift Heavy 36m 96m Improved capacity at radius
Superlift Light Up to 126m Maximum reach configuration

XCMG XGC400-I LATTICE CRAWLER CRANE

XCMG XCR90_AU 90T Rough Terrain Crane
90t maximum lifting capacity, 48m five-section main boom with jib option extending reach to 63.1m
Cummins-powered drivetrain with hydraulic torque converter, delivering strong off-road performance and fuel efficiency
Multi-mode steering system (front, rear, crab) for tight turning radius and excellent manoeuvrability on confined or uneven sites
Advanced lifting control technology, including precise load control, boom telescoping with load, and intelligent load-sensing hydraulics
Mining-ready design with high-visibility spacious cab, multi-camera monitoring, energy-saving hydraulics, and robust safety systems

XCMG XCR90_AU

XCMG XCA120G7-1AU
PRODUCT OVERVIEW
The XCMG XCA120G7-1AU is a 120-tonne all-terrain crane engineered to meet Australian operating conditions, delivering exceptional lifting performance, long reach, and reliable operation across construction, infrastructure, industrial, and major project applications.
Combining high-capacity lifting with true all-terrain mobility, the XCA120G7-1AU is ideal for contractors requiring a powerful crane capable of efficient road travel while maintaining excellent stability and precision on demanding worksites.
Built with premium driveline components, advanced hydraulic systems, and a heavy-duty multi-axle carrier, the XCA120G7-1AU delivers outstanding productivity, safety, and whole-of-life value for large-scale lifting operations.
KEY FEATURES & BENEFITS
120-tonne Rated Capacity Suitable for major construction, precast concrete, steel erection, infrastructure, and industrial lifts.
All-Terrain Capability Strong highway travel performance combined with excellent off-road mobility.
7-Section High-Strength Main Boom 66 m Smooth telescoping with strong lifting charts and outstanding reach.
Up to 66 m Main Boom + Fly Jib Options Excellent lifting height and working radius flexibility.
Advanced Electro-Hydraulic Control System Smooth, precise, and efficient crane operation.
Premium Powertrain Proven engine, transmission, and axle components for reliability and fuel efficiency.
Australian Specification Supported locally with parts, service, and technical expertise.
TECHNICAL HIGHLIGHTS
Rated Lift Capacity: 120,000 kg
Main Boom: 7-section telescopic, 66 m
Fly Jib: Fixed and optional extensions available
Boom Design: High-strength steel construction
Control System: Intelligent electro-hydraulic
Carrier: All-terrain, multi-axle configuration
Applications: Construction, civil, industrial, infrastructure, major projects, hire fleets
WHY CHOOSE THIS CRANE
True heavy-lift all-terrain capability
Exceptional lifting performance with extended reach
Smooth, accurate load control
Proven XCMG engineering and durability
Backed by experienced Australian dealer support

XCMG XCA120G7-1AU

XCMG XGC 320 Product Overview
The XCMG XGC 320 is a 320-tonne class heavy-duty lattice boom crawler crane designed for major infrastructure, mining, energy, and industrial construction projects. It delivers exceptional lifting capacity, long reach, and outstanding stability, making it ideal for demanding heavy-lift applications.
Boom & Jib Configurations
Main Boom (HB)
Recommended boom length: 22 m 64 m
Maximum standard boom length: 88 m
Optional extended boom: up to 94 m (custom)
High-strength four-chord lattice boom design
Tower Jib (HW)
Recommended length: 24 m 42 m
Maximum standard length: 60 m
Optional extension: up to 66 m (custom)
Light-Duty Boom (LB)
Boom and tower jib combination
Maximum light-duty boom length: 107.5 m
Suitable for long-reach, moderate-load lifts
Fixed Jib (HF)
Recommended length: 7 m
Maximum length: 16 m
TBM Jib (HBF)
Recommended length: 7 m
Maximum length: 10 m
Two-hook operation, interchangeable with fixed jib sections
Lifting Performance
Maximum rated lifting capacity: 320 tonnes
Maximum lifting moment: 1,870 t·m
Up to 15 operating modes across multiple boom and jib configurations
Counterweights
Car-body counterweight: 40 t
Turntable counterweight: up to 125 t
Modular slabs for optimised lifting charts
Engine & Systems
Engine: Weichai WP10 series
Rated power: 247 kW @ 1,900 rpm
Advanced hydraulic proportional control system
PLC-controlled electrical system with CAN-bus
Comprehensive safety systems including LMI and cameras

XCMG XGC320 LATTICE CRAWLER CRANE
