The Crane Connection

XCMG XGC 320 Product Overview
The XCMG XGC 320 is a 320-tonne class heavy-duty lattice boom crawler crane designed for major infrastructure, mining, energy, and industrial construction projects. It delivers exceptional lifting capacity, long reach, and outstanding stability, making it ideal for demanding heavy-lift applications.
Boom & Jib Configurations
Main Boom (HB)
Recommended boom length: 22 m 64 m
Maximum standard boom length: 88 m
Optional extended boom: up to 94 m (custom)
High-strength four-chord lattice boom design
Tower Jib (HW)
Recommended length: 24 m 42 m
Maximum standard length: 60 m
Optional extension: up to 66 m (custom)
Light-Duty Boom (LB)
Boom and tower jib combination
Maximum light-duty boom length: 107.5 m
Suitable for long-reach, moderate-load lifts
Fixed Jib (HF)
Recommended length: 7 m
Maximum length: 16 m
TBM Jib (HBF)
Recommended length: 7 m
Maximum length: 10 m
Two-hook operation, interchangeable with fixed jib sections
Lifting Performance
Maximum rated lifting capacity: 320 tonnes
Maximum lifting moment: 1,870 t·m
Up to 15 operating modes across multiple boom and jib configurations
Counterweights
Car-body counterweight: 40 t
Turntable counterweight: up to 125 t
Modular slabs for optimised lifting charts
Engine & Systems
Engine: Weichai WP10 series
Rated power: 247 kW @ 1,900 rpm
Advanced hydraulic proportional control system
PLC-controlled electrical system with CAN-bus
Comprehensive safety systems including LMI and cameras

XCMG XGC320 LATTICE CRAWLER CRANE

XCMG XGC85 85T Lattice Crawler Crane
85t maximum lifting capacity, main boom 1358m, fixed jib 719m (total reach up to 49m + 19m)
Weichai WP7 diesel engine (199kW, Euro IIIA), delivering high torque and reliable performance for heavy-duty site work
Heavy-duty crawler configuration with low ground pressure (0.087 MPa) and 30% gradeability, ideal for soft or uneven ground
Advanced hydraulic and control systems, including load-sensing LUDV hydraulics, precise micro-control, and full LMI safety monitoring
Self-assembly friendly transport design, total counterweight 28.2t, modular components for efficient mobilisation and setup

XCMG XGC85 LATTICE CRAWLER CRANE

XCMG XGTC60-AU Telescopic Crawler Crane
PRODUCT OVERVIEW
The XGTC60-AU Telescopic Crawler Crane is a highly versatile 60-tonne class lifting solution designed for projects that require strong lifting performance, compact transport dimensions, and excellent mobility on soft or uneven ground.
Manufactured by XCMG, the XGTC60-AU combines the fast setup advantages of a telescopic boom crane with the stability and low ground pressure benefits of a crawler undercarriage. This makes it an ideal solution for civil construction, infrastructure projects, industrial maintenance, and shutdown work across Australia.
Powered by a Cummins B6.7 EU Stage V engine, the XGTC60-AU delivers reliable performance, reduced emissions, and excellent fuel efficiency while maintaining smooth, precise lifting control.
KEY SPECIFICATIONS
Maximum Rated Lifting Capacity: 60 tonnes
Maximum Lifting Moment: 2,205 kN·m
Main Boom Length: 12 46.5 metres
Fixed Jib Length: 9.5 m / 16 m
Maximum Boom + Jib Length: 62.5 metres
Engine: Cummins B6.7 209 kW @ 2,200 rpm (EU Stage V)
Maximum Travel Speed: 2.4 km/h
Gradeability: 45%
Crawler Shoe Width: 760 mm
Average Ground Pressure: approx. 0.08 MPa
Total Operating Weight: approx. 68.4 tonnes
FEATURES & BENEFITS
Telescopic Boom Design Fast setup and efficient operation without lattice boom assembly delays.
Crawler Undercarriage Excellent stability and low ground pressure for soft or uneven ground conditions.
Advanced Electro-Hydraulic Control System Smooth, precise lifting and slewing performance.
360° Slewing Capability Strong slewing bearing with soft start and stop control.
Operator-Focused Cabin Air-conditioned tilt-up cab with excellent visibility and ergonomic controls.
Flexible Counterweight Configuration Up to 19.5 tonnes with self-assembly capability.
Comprehensive Safety Systems Load moment indicator, virtual wall, cameras, fault diagnostics, and interlock protection.

XCMG XGTC 60-AU

XCMG
Model: XGC400-1
Lattice Boom Crawler Crane
Maximum Rated Capacity: 400 tonne
Standard Heavy Boom Range: 24m 84m
Standard Light Boom Range: 42m 108m
Superlift Heavy Boom Range: 36m 96m
Superlift Light Boom Maximum: Up to 126m (with superlift configuration)
Minimum Boom Length: 24 metres
Maximum Boom Length (Light + Superlift): 126 metres
Boom Configuration Summary Table
Configuration Boom Range Notes
Heavy Boom 24m 84m High capacity configuration
Light Boom 42m 108m Extended reach, reduced weight
Superlift Heavy 36m 96m Improved capacity at radius
Superlift Light Up to 126m Maximum reach configuration

XCMG XGC400-I LATTICE CRAWLER CRANE

XCMG XGTC 100 100T Telescopic Crawler Crane
100T Lifting capacity 13.3m-52-Five section full power boom
17.5 Fly jib , Cumming QSL9 EU Stage III Diesel Engine , High Visibility cab with 15 Degree tilt .Self-erecting counterweight system with configuration sensing and remote control. Integrated access steps and mounting for handrails. Load charts available for various counterweight configurations.
Four upper counterweight configurations:
26,000 kg
18,500 kg
11,000 kg
0 kg
Carbody countweights:
2×45000kg
Assembly Jacks
Jacks mounted to carbody structure with radio remote control , easily assembly/disassembly for transport. Includes 4 octagonal outrigger pads.

XCMG XGTC 100

XCMG XLC110MC 110 Tonne Crawler Crane
General Description
The XLC110MC is a 100-tonne class lattice boom crawler crane designed for heavy lifting applications including civil construction, infrastructure, mining, and industrial projects.
Key Specifications
Maximum lifting capacity: 110 t
Main boom length: 1364 m
Fixed jib length: 719 m
Maximum boom + jib: 52 m + 19 m
Performance
Hoisting speed: up to 140 m/min
Luffing speed: up to 75 m/min
Slewing speed: 2.1 rpm
Travel speed: 1.9 km/h
Gradeability: 30%
Engine
Engine: Weichai WP7G270E301
Rated power: 199 kW @ 2100 rpm
Emission: China Stage III / EU Stage IIIA
Weights & Transport
Operating weight: approx. 98 t
Ground pressure: 0.098 MPa
Max transport piece: 23.5 t
Transport dimensions: 13.6 × 3.4 × 3.1 m
Safety & Controls
CAN-bus electro-hydraulic controls
12.1-inch HD touchscreen
Load Moment Indicator (LMI)
Emergency stop & slew lock
Camera monitoring system

2026 XCMG XLC110MC
